1000W Water Turbine Generator, All Copper Wire Oblique Impact Hydroelectric Generators, 1KW High Power 220V Single Phase Micro Hydro Generator for Outdoor

Specifications:Product name: Hydro generatorPower: 1000WFlow: 0.01m³/sWater head: 10-15mSpeed: 500-1500 rpmVoltage: 220VCurrent: 4.5AInner diameter of valve connector: 63mmFeatures: It is most suitable for farmers in mountainous areas with sporadic and tiny hydropower resources to solve the power generation equipment for lighting, televisions, etc.Notes:The pipeline should be installed straight, with minimal bending, and the angle between the pipeline and the horizontal should not be less than 25 degrees, otherwise the pipeline will grow, the head loss will be large, and the power generation will be insufficient.

• Simple Design: The turbine is composed of a simple spoon-shaped blade, which consists of a casing, a nozzle, an impeller and a generator. When high-speed water flows from the nozzle to the blade, the blade rotates at high speed, thereby driving the generator to generate electricity
• Pure Copper Coil: This hydroelectric generator uses a pure copper core coil, which has lower resistance and better conductivity, thereby improving power generation efficiency
• High Power: The maximum power of this water turbine is up to 1000W, and the voltage is 220V. Inner diameter of valve connector: 63mm
• Requirements: Single-phase hydroelectric generator required water head: 10-15m, flow: 0.01m³/s, speed: 500-1500 rpm, current: 6.5A, Inner diameter of valve connector: 63mm
• Wide Application: Outdoor generators use hydropower to generate electricity, which is energy-saving and environmentally friendly. It can be used in mountainous areas with flowing water, or remote areas
