BT30 5.5KW/7.5KW 380v/220v ATC Motor Automatic Pneumatic with Seal Water Cooled Motor for Metal/Wood(5.5KW,220v)

Engine Radiator Cooling Fan Motor1 pcs & 55KW75KW 380v 220v BT30 ATC Motor Water CoolingCeramic ball bearings 7008CP4DT*2 & 7007CP4DT Imported BearingsBasic parameterPower55kw/7.5KWVoltage: 380vCurrent:12A/15ANumber of poles:4 tool handle:BT30Rated frequency: 600Hz, speed 18000RPMMaximum frequency:800Hz, speed 24000RPMBearing:Ceramic ball bearings 7008CP4DT*2 & 7007CP4DT Imported BearingsNet Weight 29kg31kgNote1 During installation please be careful and pay attention to personal safety to avoid injury accidents during installation. At the same time, pay attention to the anti-rust protection of the main shaft, and avoid bumping the important installation surface of the main shaft during the installation process. During the assembly process, please conduct necessary anti-rust treatment on the main shaft cone surface and cone hole before work every day to prevent the main shaft from rusting and affecting the main shaft accuracy;2. During the machine tool startup, the air seal device should be opened in the whole process. After the machine is shut down and the stops rotating, the air seal device must remain for a certain time until no water or dirt runs into the and the machine body is fully cooled;3. It is recommended that the tool used for the should be the tool that meets the dynamic balance grade within G2.5 of ISO1940 specification. The surface should be cleaned regularly to avoid the dust blowhole or dust disk being blocked at the lower end of the due to the accumulation of chips;4. It is forbidden to strike the main shaft, shaft core end face, cone surface, etc. It is forbidden to use abrasive paper and grinding wheel for wiping and grinding.5. When installing the main shaft horizontally, make sure that the drainage hole at the front of the main shaft is vertical and downward. It is strictly prohibited to spray air into the nose of the main shaft to prevent forei
