CS20 Salt Chlorinator 20g/h Chlorine Output for 11000-23000Gallons Pools with Self Cleaning Low Salt Alarm 100-240V

The Autopartsfreer CS6 Salt Chlorinator is designed for pools ranging from 13 to 27 cubic meters, delivering 6g/h of chlorine to keep water clean and safe. Equipped with advanced microcomputer technology, it combines a controller and chlorinator in one unit for easy installation and space efficiency, with water inlet and outlet on the same axis to simplify pipe arrangement.

• 【20g/h Chlorine Output for 45-90m³ Pools】The CS20 is engineered for large residential or small commercial pools (45-90 cubic meters), delivering 20g/h of chlorine to maintain clean and safe water. It offers two output settings: HALF (10g/h) for economical use during low demand and FULL (20g/h) for full disinfection capacity, adapting to your pool’s needs.
• 【Self Cleaning & Easy Maintenance】Features a removable titanium plate with auto-reverse polarity, supporting 4h/8h/12h self-clean cycles to prevent calcium buildup. The movable structure simplifies cleaning and replacement, extending the electrode’s service life and reducing upkeep efforts.
• 【Comprehensive Safety & Alarm Functions】Equipped with water flow protection (activates only when flow ≥2m³/h) to save energy and protect the device. A low salt alarm (red light flash + E5 code) alerts when salinity drops below 2700PPM (ideal range 2700-4500PPM). It also monitors water temperature (10-45°C) and voltage, with error codes for quick troubleshooting.
• 【Flexible Operation & Memory Function】Customize operation time with 5 settings (4h/6h/8h/12h/24h) to match pool usage. The system automatically saves settings during power outages and resumes operation once power is restored, ensuring consistent performance without manual resetting.
• 【Easy Installation & Wide Compatibility】Integrated controller and chlorinator save space, with in/out ports on the same axis to simplify pipe arrangement. Compatible with 50mm/1.5" pipes and 32mm/38mm flexible hoses (no glue needed for hoses, use locking hoops). Supports horizontal, vertical (bottom-to-top flow), or bypass installation, working seamlessly with pool filters and timers. Requires a 100-240V AC power source with leakage protection.
