DB9 Female to VGA Female 15Pin Three-Row Data Transmission Cable, VGA to DB9 Serial RS232 Data Cable for Mutual Transmission of Signals Between 9Pin Video Devices and Computers 50CM

Specification Connector A Type:VGA Connector A Gender:Female Connector B pin count:15Pin Connector B Type:DB9 Connector B Gender:Female Connector A Pin Count:9pin Wire length:50CM

• VGA to DB9 signal cable, female to female, 15-pin to 9-pin, VGA three-row, RS232 serial port data cable, 50CM
• Some video devices are 9-pin, but our computer graphics cards are all 15-pin, which is the purpose of this cable. It adopts UL standard design and is suitable for connecting computers and serial port devices and transmitting signals between them.
• The wiring method of this cable: 1-1, 2-2, 3-3, 4-13, 5-14, 6-6, 7-7, 8-8, 9-10, 9-11. (You need to understand the wiring method or check the wiring method description in the video device product manual)
• Using polyethylene HDPE inner insulation, pure copper wire core + shielding, high-fidelity design, strong anti-interference ability, reduced transmission signal attenuation, and good use effect.
• Please note: This cable is compatible, not universal. Please match the interface and line, both are indispensable. Some devices may not be able to connect. The cable is absolutely good. If there is a compatibility issue, please consider it carefully before buying. Thank you for your understanding and support!!!
