JK2831 Digital LCR Meter 37 Frequency Points 200kHz LCR Meter
Product details
| Management number | 210911418 | Release Date | 2026/04/04 | List Price | $352.00 | Model Number | 210911418 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
■ Low cost, high performance, small volume LCR tester ■ 4.3 inch TFT LCD display ■ Soft power switch ■ Optional operating interface in English and Chinese ■ Maximum 200kHz test frequency ■ 6 bit readings resolution ■ 10mVrms-2.0Vrms Programmable test level。Built-in 0- + 5V/50mA bias source ■ DCR Test function,50mV-2V,Programmable test level, resolution 10mΩ ■ Ls-Rd/Lp-Rd function (L, Rd is displayed simultaneously) ■ Maximum test speed 13ms/ times ■ 30Ω、100Ω signal source impedance ■ Voltage and current monitoring and automatic level adjustment function ■ Built-in comparator, 10 gear sorting and counting function ■ It supports U disk file storage and can be upgraded by U disk. ■ RS232,RS485,USB,HANDLER,GPIB interface ■ Parameter test function of single transformer transformer (only part type) ■ Rd means DCR
- inductance meter, digital LCR tester, resistance meter, ESR meter, capacitance meter
| Brand Name | Jinko |
|---|---|
| Style Name | Digital |
| Manufacturer | Jinko |
| Power Source | Battery Powered |
| Measurement Type | LCR Meter |
