Milescraft 1327 Pocket Jig 400 – Self-Clamping, Heavy-Duty, All-Metal Pocket Hole Jig. Complete Kit with Bit, Driver, and Screws
Product details
| Management number | 213603164 | Release Date | 2026/04/12 | List Price | $37.60 | Model Number | 213603164 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Looking to create pocket hole joints like a PRO? The Milescraft PocketJig400 is the professional pocket hole kit that delivers. Creating professional quality results has never been easier. The durable metal construction of the PocketJig400 is built to last. Solid steel bushings adjust both vertically and horizontally to fit your workpiece with a simple twist of a knob. Laser etched scales help to set the position of the drill guides from .25” to 3” apart on boards from ½” to 1-1/2” (12-38mm) thick. The PocketJig400’s convenient storage drawer contains markings for all common board thicknesses make setting the depth stop simple and easy. When it’s time to drill, the flow-through bushing design allows chips to exit the rear, helping keep pocket holes smooth and clean of debris. The ¾” tall base of the PocketJig400 is the perfect height for creating a custom pocket hole work station. Mount the jig to a work surface and use common ¾” thick boards to extend the base of the jig to provide more horizontal support for workpieces. Free plans are included with the kit. For mobile or repair jobs, the clamping wall of the PocketJig400 is removable, turning it into a hand-held jig that fits and clamps almost anywhere. Included with the PocketJig400 are all the accessories required to get started.
- Height adjustable bushing blocks contain two, 3/8" steel drill guides that can be positioned for drilling boards from 1/2” up to 1-1/2” thick
- Drill guides adjust horizontally to position holes between 3/4” and 3” apart
- Laser etched markings in inches and metric
- Steel toggle clamp with micro-adjust clamp-head dials in perfect clamping pressure for different board thicknesses
- Convenient storage drawer holds bit, driver, depth stops, and more
- L-Base can be removed from main body and used for mobile pocket hole projects and repairs
| UPC | 737888132706 |
|---|---|
| Color | White and Red |
| Brand Name | Milescraft |
| Unit Count | 1.0 Count |
| Item Weight | 1 Pounds |
| Manufacturer | Milescraft |
| Model Number | 1327 |
| Material Type | Aluminum |
| Item Type Name | Pocket Jig 400 |
| Item Dimensions | 13.39 x 5.51 x 5.12 inches |
| Number of Pieces | 1 |
| Included Components | 10 Pocket Plugs, 3/8” Pocket Hole Bit, 3/8” Split-Ring Depth Stop, 3mm Allen Wrench, 60 Pocket Hole Screws, Pocket Jig 400, T20 Magnetic Driver |
| Manufacturer Part Number | Milescraft - 1327 |
| Global Trade Identification Number | 00737888132706 |
