Watts LFFBV-4 Series 2" Lead-Free 2-Piece Full Port Chrome-Plated Brass Ball Valve with Female Threaded End Connections, Copper Silicon Alloy Body, Adapter, Steel Handle
Product details
| Management number | 211105158 | Release Date | 2026/04/04 | List Price | $26.04 | Model Number | 211105158 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Series LFFBV-4, LFFBVS-4 2-Piece, Full Port, Brass Ball Valves are suitable for a full range of liquids and gases in residential and commercial applications. These valves feature an adjustable packing for longer service life, a bottom loaded blow-out proof stem for safety, a fluorocarbon elastomer stem O-ring to prevent stem leaking at installation, and are rated to 600psi WOG/150psi WSP 1⁄4"–2" and 400psi WOG/125psi WSP 21⁄2"–3". The LFFBV-4, LFFBVS-4 features lead free construction to comply with lead free installation requirements.
- BRASS BALL VALVE: Crafted from high-quality lead-free copper silicon alloy with brass ball, this 2" two-piece full port ball valve ensures safe and reliable use in both residential and commercial potable water applications for a full range of liquids and gases.
- COMPREHENSIVE FEATURES: This ball valve is built with a lead-free copper silicon alloy body and is equipped with a chrome-plated lead-free brass ball, female threaded end connections, bottom-loaded blowout-proof stem, fluorocarbon elastomer O-ring, virgin PTFE seat, thrust washer, adjustable stem packing seal, lead-free brass adapter, and steel handle.
- DURABLE CONSTRUCTION: The lead-free copper silicon alloy body construction ensures long-lasting, reliable performance in commercial and industrial potable water applications. Additionally, the ball valve is rated for 600 psi (41 bar) WOG non-shock and 150 psi (10.3 bar) WSP, ensuring reliable performance under various conditions.
- FULL PORT: The full port design of this valve allows for maximum flow capacity with minimal pressure drop, enabling the passage of liquids and gases without significant resistance and ensuring efficient and effective operation in various systems.
- EVERY DROP COUNTS: Water. It's in our name and close to our hearts. Since 1874, Watts Water Technologies has been delivering innovative technologies that make the world's most precious resource safe and accessible. Everything we design is made to keep the Earth's most precious resource safer, cleaner, and more useful for our customers. Our family of brands offers one of the most varied product lines in the world, with world-class, water-related solutions.
| UPC | 098268805512 |
|---|---|
| Size | 2 Inch |
| Brand Name | Watts |
| Unit Count | 1.0 Count |
| Valve Type | Ball Valve |
| Manufacturer | Watts |
| Model Number | LFFBV-4 |
| Material Type | Bronze |
| Connector Type | Threaded |
| Item Type Name | Full Port Ball Valves |
| Exterior Finish | Brass |
| Item Dimensions | 3.25 x 5 x 8.25 inches |
| Number of Ports | 2 |
| Maximum Pressure | 600 Pound per Square Inch |
| Number of Pieces | 1 |
| Specification Met | MSS-SP-110 |
| Included Components | ball vavle |
| Inlet Connection Size | 2 Inches |
| Inlet Connection Type | National Pipe Tapered |
| Outlet Connection Size | 2 Inches |
| Outlet Connection Type | NPT |
| Manufacturer Warranty Description | Watts (the "Company") warrants each product to be free from defects in material and workmanship under normal usage for a period of one year from the date of original shipment. In the event of such defects within the warranty period, the Company will, at its option, replace or recondition the product without charge |
| Global Trade Identification Number | 00098268805512 |
